Sort | Name | Specification |
Size | Length | 18m |
Width | 10m | |
Height | 3m | |
Total area | 180m² | |
Steel structure | Column | Square tube |
Beam | Square tube | |
Purlin | “C” section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1200*930 aluminum sliding window |
Door | 880*2040 steel door |
◪1.Modular Villa is easier to build, lower cost, significantly time-saving and labor saving comparing to the traditional civil buildings. |
◪2.Internal design can be customized as your own stylish apartment, with bedrooms, living room, kitchen and toilet inside. |
◪ 3.External decoration sheet / internal wall paper applicable for better appearances inside / outside the house. |
◪ 4.Ceramic tile, ceiling, sit down toilet, wash basin and shower are conventional arrangements. |
◪ 5.Easy to build. The house is connected by bolt and screw. 6 labors one team, each day can install 100 square meter. |
Material parameters
Main steel:C section steel for column&beam;
Wall panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;
Roof panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;
Window:Aluminum sliding window;
Door:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door;
ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/m2 |
Live load capacity of roofing: | 0.6 kn/m2 |
External and internal wall heat transmission coefficient: | 0.35 kcal/m2hc |
Wall permitted loading: | 0.6 kn/m2 |
Materials for the wall and roof: | EPS/IEPS/Rock wool/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Accessories: | Ceramic tile,ceiling,toilet,wash basin |
Delivery time: | Normally 20-25 days |
This steel villa can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
