Sort | Name | Specification |
Size | Length | 76.61m |
Width | 18.76m | |
Height | 6m | |
Total area | 1437.2m2 | |
Steel structure | Column | "H" section steel |
Beam | "H" section steel | |
Purlin | “C” section steel | |
Panel | Wall panel | 0.426mm single steel sheet |
Roof panel | 0.426mm single steel sheet | |
Accessories | Window | 1200*925 aluminum sliding window |
Door | Electric roller door |
This steel structure building is used as the warehouse in Uganda. Ventilation balls are installed for the air flow on the top of the warehouse.
To keep safer and avoid the water to come inside, it needs to build a one-meter high wall before installing the wall panel.
◪1.The structure is strong “H” section steel and “C” section steel. |
◪2.Single steel sheet or sandwich panel for the wall and roof. |
◪3.Normally requires cement foundation of 600mm at least. |
◪ 4.The height of the brick or concrete wall from 1m to 2m is suggested, for a better waterproofing performance before installing prefabricated wall panels. waterproofing performance before installing prefabricated wall panels. |
◪ 5.All the steel structure is painted and anti-rust which can be normally used for more than 30 years without any building wastes. |
◪ 6.Easy to build. The building is connected by bolts and screws. 6 labors constitute one team, can install areas of 300 square meters each day. |
Material parameters
Main steel:"H" section steell for column & beam;
Wall panel:0.426mm single steel sheet;
Roof panel:0.426mm single steel sheet;
Window:Aluminum sliding window;
Door:Electric roller door;
Ridge capping:0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Wall and roof panel: | EPS/IEPS/ROCK WOOL/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Delivery time: | Normally 20-25 days |
Container loading(50mm): | 900㎡/HQ |
This workshop can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
