Wholesale k19 prefabricated houses china price WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Brand
1. prefab houses is applicable to a prefabricated houses china price. Its materials prove to have premium plasticity and toughness
2. Its stable quality is achieved by the efforts of the design team, engineer team, innovation team, and QC team. we provide customized service for our labor camp,prefabricated house companies.
3. Its quality inspection standards highly meets the international indicators. [卖点、特色句
4. The product is easy to move and install. The New prefab homes,prefabricated houses by chinese companies is easy to assemble and has plenty of prefabricated concrete houses.
| Sort | Name | Specification |
Size | Length | 11.08m |
| Width | 7.44m | |
| Height | 2.85m | |
| Total area | 67.81m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm rock wool sandwich panel |
| Roof panel | 50mm rock wool sandwich panel | |
Accessories | Window | 1740*925 Aluminum sliding window |
| Door | EPS sandwich door, steel door | |
Mexico Project. This prefabricated house is used as the factory kitchen.
The material of the wall and roof is the 50mm fire proof rock wool sandwich panel.
There are exhaust fan and fridge installed in it.
◪1. The unit figure for K house dimension is K. 1k=1.82m |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3. K house is commonly used with qualified waterproof, fireproof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
K-House 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. As a prefabricated houses china price manufacturer, Guangdong WELLCAMP BUILDING MATERIALS CO., LTD, has a well-earned reputation for prefabricated house companies.
2. Our prefab houses is easily operated and need no additional tools.
3. In partnership with the most respected brands in the world, WELLCAMP, WELLCAMP prefab house, WELLCAMP container house develops a wide range of products. Check now!
