WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated villa apartment wholesale
1. Simple in structure, moderate in weight, prefabricated villa is easy to assemble, disassemble and move. It has large space utilization rate, which is in line with the general temporary building construction standards.
2. With stable quality, prefabricated villa can customize according to customer requirements. All its steel bars have anti-rust treatment, which can provide long-term durability
3. This product is noted for durability. Its outer wall contains fiber components and has excellent toughness and aging resistance. It is made of environmentally-friendly materials to protect the ecological system
4. This product has a smooth surface. Throughout the sanding process, the sheets and welds are sanded to remove any rough corners and jags. The product helps save energy and cost in the process of installation
5. This product is able to resist harsh environments, such as on ocean-going vessels or sprayed with road salt while transported on roads. It is frequently displayed in the international exhibition, such as the Canton Fair
| Sort | Name | Specification |
Size | Length | 9.76m |
| Width | 6.71m | |
| Height | 2.8m | |
| Total area | 65.49 m² | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | “C” section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1200*930 aluminum sliding window |
| Door | 880*2040 steel door | |
◪1.Modular Villa is easy to build, low cost, significantly time-saving and labor saving comparing to the traditional civil buildings. |
◪2.Internal design can be customized according to your own stylish apartment with bedrooms, living room, kitchen and toilet inside. |
◪ 3.EExternal decoration sheet / internal wall paper is used for better appearances of the house. |
◪ 4.Ceramic tile, ceiling, sit-down toilet, wash basin and shower are conventional arrangements. |
◪ 5.Easy to build. The house is connected by bolts and screws. 6 labors constitute one team, which can install an area of 100 square meters each day. |
Steel Villa 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Materials for the wall and roof: | EPS/IEPS/Rock wool/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Accessories: | Ceramic tile,ceiling,toilet,wash basin |
Delivery time: | Normally 20-25 days |
This steel villa can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. The factory has newly introduced many advanced manufacturing facilities and testing equipment. The technological advantages have translated into improving overall productivity.
2. According to our service core of prefabricated villa , our business has been blooming. Get info!
