WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefab houses wholesale for office1
1. This prefab houses is developed using premium quality material in compliance with the international quality standards. It is made of environmentally-friendly materials to protect the ecological system
2. [企业简称] has accumulated rich production experience during the development for many years. Besides, we have professional engineers, advanced production equipment, and strong technical force. Our prefab houses is superior in quality and excellent in performance.
3. It meets some of the world’s most stringent performance standards. It can be freely combined with other products to maximize the space
4. The product is handled with the utmost quality and expertise. The product has a good bearing capacity which is shock-resistant
| Sort | Name | Specification |
Size | Length | 10K(18.36m) |
| Width | 3K(5.62m) | |
| Height | 6P | |
| Total area | 242.91 m² | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1740*925 aluminum sliding window |
| Door | Steel door | |
One side of this modular building are bedrooms, another side is the public bathrooms.
The walkway and stair is one meter wide. Around 128 people live in this green prefabricated house.
◪1. The unit figure for K house dimension is K. 1k=1.82m |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3. K house is commonly used with qualified waterproof, fireproof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
K-House 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD, mainly specializing in designing, producing and selling concrete houses in usa , is a market notable manufacturer in China. Thanks to years of good practices, we have gained official recognition. For example, we have been awarded the title of "China Quality Award" for many times.
2. Our factory is well-equipped. We have advanced machines and experienced staff. This versatile combination of man and machinery means our production is calibrated, recalibrated and fine-tuned to meet specific requests.
3. Our company has established an easy-to-cooperate team. At every step of the project-quotation, design, manufacturing, and maintenance, they will be there to quickly provide the answers the customer needs. We are a company with a social and ethical mission. Our management contributes their knowledge to help companies manage performance around labor rights, health and safety, the environment and business ethics. Get price!
