WELLCAMP, WELLCAMP prefab house, WELLCAMP container house low cost modular house manufacturer for countryside
1. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house cost of prefabricated houses is fabricated using optimum quality raw materials and pioneering technology. The service life of the product is more than 20 years
2. [企业简称] has large-scale production plants, modern production equipment, intelligent production lines, senior designers and engineers. Besides, we have established scientific and standardized production processes and professional and rigorous quality assurance system. Our production strength is unanimously recognized in the industry. Our modular house has stable performance and excellent quality.
3. The product has standard height and length measurements and as such, it provides modular elements that can be combined into larger structures. The product helps save energy and cost in the process of installation
4. This product has excellent water tightness. The water resistance test has proved its strength in resisting deterioration and breakdown caused by water. The product is easy to move and install
| Sort | Name | Specification |
Size | Length | 11.7m |
| Width | 7.35m | |
| Height | 2.85m | |
| Total area | 85.995m2 | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | “C” section steel | |
Panel | Wall panel | 50mm EPS sandwich panel with PVC decoration sheet |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1200*930 aluminum sliding window |
| Door | steel door | |
◪1.Modular Villa is easy to build, low cost, significantly time-saving and labor saving comparing to the traditional civil buildings. |
◪2.Internal design can be customized according to your own stylish apartment with bedrooms,living room, kitchen and toilet inside. |
◪ 3.External decoration sheet / internal wall paper is used for better appearances of the house. |
◪ 4.Ceramic tile, ceiling, sit-down toilet, wash basin and shower are conventional arrangements. |
◪ 5.Easy to build. The house is connected by bolts and screws. 6 labors constitute one team, which can install an area of 100 square meters each day. |
Steel Villa 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 7 |
Snow load capacity of roofing: | 0.6 kn/㎡ |
Live load capacity of roofing: | 0.6 kn/㎡ |
External and internal wall heat transmission coefficient: | 0.35 kcal/㎡hc |
Wall permitted loading: | 0.6 kn/㎡ |
Materials for the wall and roof: | EPS/IEPS/Rock wool/PU |
Thickness of the wall and roof: | 50mm/75mm/100mm |
Accessories: | Ceramic tile,ceiling,toilet,wash basin |
Delivery time: | Normally 20-25 days |
This steel villa can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is a growing and active producer of cost of prefabricated houses . We put great emphasis on technology of modular house .
2. Our production capacity occupies steadily in the forefront of the modular house china industry.
3. All our technical staff are rich in experience for prefab modular house . We will adhere to the strict green production approach. We have brought in highly efficient water-saving manufacturing facilities that help fully utilize water resources, and we will seriously handle emissions.
