Tailored Camp Solutions to Meet  Custom Needs.

section prefab guest house apartment for labour camp 1
section prefab guest house apartment for labour camp 2
section prefab guest house apartment for labour camp 3
section prefab guest house apartment for labour camp 4
section prefab guest house apartment for labour camp 5
section prefab guest house apartment for labour camp 6
section prefab guest house apartment for labour camp 7
section prefab guest house apartment for labour camp 8
section prefab guest house apartment for labour camp 9
section prefab guest house apartment for labour camp 10
section prefab guest house apartment for labour camp 1
section prefab guest house apartment for labour camp 2
section prefab guest house apartment for labour camp 3
section prefab guest house apartment for labour camp 4
section prefab guest house apartment for labour camp 5
section prefab guest house apartment for labour camp 6
section prefab guest house apartment for labour camp 7
section prefab guest house apartment for labour camp 8
section prefab guest house apartment for labour camp 9
section prefab guest house apartment for labour camp 10

section prefab guest house apartment for labour camp

Price Term:
FOB, CIF, CFR
Port:
Nansha/Huangpu Port
Payment Term:
TT/LC
MOQ:
100 Square Meters
Model:
Wellcamp K-1
House Style:
k Prefabricated House
Delivery Time:
20-25 days
Brand Name:
WELLCAMP
Inquiry
Company Advantages
1. prefab guest house is produced with high craftwork. It can be freely combined with other products to maximize the space
2. This product is revolutionizing several areas, not only the marine cargo but even the home — something that was not expected or could be imagined in the last century. The product is wind-resistant and can withstand more pressure
3. prefab guest house is made from excellent materials and is free of harmful substances and odor. It is excellent in stability and durability and is effective in resistance to wind, earthquake, high temperature, and corrosion. It is safer, more reliable and eco-friendly than other similar products.
4. prefab guest house is manufactured based on the concept of environmental protection. It has excellent performances such as heat insulation, heat preservation, flame retardant, sound insulation and anti-corrosion property. With high recycling rate, it can effectively help customers save unnecessary expenses.
5. prefab guest house is manufactured based on superior materials and reasonable structural design. It is excellent in the resistance to impact, abrasion, corrosion, and aging. Easy to clean, it can save a certain amount of maintenance costs for users.
  ◆◆ Product Detail


SortNameSpecification



Size


Length11.08m
Width7.44m
Height2.85m
Total area             87.98m2



Steel structure


Column"C"  section steel
Beam"C"  section steel
Purlin"C"  section steel


Panel


Wall panel50mm rock wool sandwich panel
Roof panel50mm rock wool sandwich panel


Accessories


WindowAluminium alloy sliding window
 DoorRock wool door


WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Modular homes for Oman labour camp, China

undefined


undefined


undefined

      Middle East Prefab Labor Camp Project. There are around 1000 rooms for the labor workers to live in.

      This 88㎡ apartment has a bedroom, toilet and kitchen. It stands on a solid concrete foundation.




  ◆◆ Product  Features


1. The unit figure for K house dimension is K. 1k=1.82m

2. K house can be done as 1 floor,2 floors or 3 floors building.

      Figures for house with different stories: One floor=3P, two floors=6p, three floors = 9p (1P=0.95m ).

3. K house is commonly used with qualified waterproof, fireproof (EPS/Rock wool/IEPS/PU sandwich panel),

      heat insulation and sound insulation performance.

4. K house uses reusable materials and is more environment-friendly

       compared to traditional buildings. It can be assembled and disassembled six times.

5.K house is Anti worm and ant. All steel structures are well painted and

      anti-rust which can be normally used for over 15 years with very limited amount of building wastes.

6.K house only requires level concrete floor for the foundation.

7.6 labors constitute one team, which can install areas of more than 300 ㎡ each day.


  ◆◆ Main   Material



K-House 3D model


undefined


Material parameters

 Main steel:C section steel for column & beam;

Wall panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Roof panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Window:Aluminum sliding window;

Door:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door;

Ridge capping:   0.326/0.376/0.426mm single steel sheet.


  ◆◆ Product  Parameter


Wind resistance

Grade 11(wind speed≤120 km/h)

Earthquake resistance

Grade 7

Snow load capacity of roofing

0.6 kn/m²

Live load capacity of roofing

0.6 kn/m²

External and internal wall heat transmission coefficient

0.35 kcal/m²hc

Wall permitted loading

0.6 kn/m²

Second floor load capacity

180kg/m²

Live load of corridor

2.5kn/m²

Density of EPS

12 kg/m²

Delivery time

Normally 20-25 days

Container loading

300-320 m² /HQ


  ◆◆ Product    Installation


Installation Photos


Installation Video




  ◆◆ Real Map   Display


WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Modular homes for Oman labour camp, China -8

This prefab house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house  are very environment-friendly. It can be assemed and disassemed for six times. For more information about it, welcome to contact us.


  ◆◆ Certificates





Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is a customer-focused company focused on manufacturing low price steel structure prefabricated house . Over the years, our company has been continuously developing and expanding the scope and updating capabilities.
2. Our company has experienced project management. They can quickly identify opportunities for cost-saving, de-risking and accelerating the introduction of technology and improved processes into customers' businesses.
3. Focusing on building a future-oriented prefab guest house is our aim. Please contact.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
