Company Advantages 1. The product features a high anti-deformation property. Base on the management tenet of' Quality first and credit supreme', WELLCAMP, WELLCAMP prefab house, WELLCAMP container house would serve the customers with faith and high sense of responsibility to cooperate and create the brilliant future together. 2. Its materials prove to have premium plasticity and toughness. Being a quality-oriented organization, we assure WELLCAMP, WELLCAMP prefab house, WELLCAMP container house clients that WELLCAMP, WELLCAMP prefab house, WELLCAMP container house range of prefab warehouse is highly durable and easy to install. 3. The design of the product is a blend of simplicity and utility. Whatever in material or in design, prefab warehouse cost is impeccable. 4. By using the product, no construction waste will be generated, We Becomes A Recognized Leader In steel warehouse, prefab warehouse prices, prefab warehouse buildings Industry After Years Of Endeavors. 5. All its steel bars have anti-rust treatment, which can provide long-term durability, WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Has Rich Experience In Manufacturing steel workshop, prefab steel warehouse. 6. It is highly evaluated by customers around the world, such as the Middle East, Africa, and Southeast Asia, WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Has Big Production Volume Of prefabricated warehouse, prefab warehouse office. 7. It's only natural that WELLCAMP, WELLCAMP prefab house, WELLCAMP container house would hit markets. It can be freely combined with other products to maximize the space 8. In the steel warehouse industry, WELLCAMP, WELLCAMP prefab house, WELLCAMP container house now is a leading manufacturer in the market. The product helps save energy and cost in the process of installation 9. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house values the innovation and development of steel workshop which attracts more and more customers. It is frequently displayed in the international exhibition, such as the Canton Fair
◆◆ Product Detail
Sort
Name
Specification
Size
Length
76.61m
Width
18.76m
Height
6m
Total area
1437.2m2
Steel structure
Column
"H" section steel
Beam
"H" section steel
Purlin
“C” section steel
Panel
Wall panel
0.426mm single steel sheet
Roof panel
0.426mm single steel sheet
Accessories
Window
1200*925 aluminum sliding window
Door
Electric roller door
This steel structure building is used as the warehouse in Uganda. Ventilation balls are installed for the air flow on the top of the warehouse.
To keep safer and avoid the water to come inside, it needs to build a one-meter high wall before installing the wall panel.
◆◆ Product Features
◪1.The structure is strong “H” section steel and “C” section steel.
◪2.Single steel sheet or sandwich panel for the wall and roof.
◪3.Normally requires cement foundation of 600mm at least.
◪ 4.The height of the brick or concrete wall from 1m to 2m is suggested, for a better waterproofing performance before installing prefabricated wall panels.
waterproofing performance before installing prefabricated wall panels.
◪ 5.All the steel structure is painted and anti-rust which can be normally
used for more than 30 years without any building wastes.
◪ 6.Easy to build. The building is connected by bolts and screws. 6 labors
constitute one team, can install areas of 300 square meters each day.
◆◆ Main Material
Workshop 3D model
Material parameters
Main steel:"H" section steell for column & beam;
Wall panel:0.426mm single steel sheet;
Roof panel:0.426mm single steel sheet;
Window:Aluminum sliding window;
Door:Electric roller door;
Ridge capping:0.426mm single steel sheet.
◆◆ Product Parameter
Wind resistance:
Grade 11
Earthquake resistance:
Grade 7
Snow load capacity of roofing:
0.6 kn/㎡
Live load capacity of roofing:
0.6 kn/㎡
External and internal wall heat transmission coefficient:
0.35 kcal/㎡hc
Wall permitted loading:
0.6 kn/㎡
Wall and roof panel:
EPS/IEPS/ROCK WOOL/PU
Thickness of the wall and roof:
50mm/75mm/100mm
Delivery time:
Normally 20-25 days
Container loading(50mm):
900㎡/HQ
◆◆ Product Installation
Installation Photos
Installation Video
◆◆ Real Map Display
This workshop can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
◆◆ Certificates
Company Features 1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is a leading supplier of steel warehouse which always provides fashionable and excellent steel workshop. - We have carved a niche amongst the most trusted names in this business, engaged in offering a comprehensive range of prefabricated warehouse. - We are prefab warehouse specialists, delivering one of the widest ranges of steel warehouse on the market. 2. Please Contact Us! With Advanced Equipment And Technique, WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Can Offer High Quality steel workshop, prefab warehouse cost, prefab warehouse prices To Customers. There Are Many Kinds Of Models On Our Website, Welcome Your Visit. - Practice Makes Perfect. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Offers The Finest prefabricated warehouse, prefab warehouse buildings, prefab steel warehouse To Suit Any Budget. Call Now! - God Helps Those Who Help Themselves. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house Offers A Huge Choice Of steel warehouse, prefab warehouse office, prefab warehouse for sale With New Design And Comfortable Materials. Get Quote! 3. Without a mutual goal in mind, Guangdong WELLCAMP BUILDING MATERIALS CO., LTD couldn't have been so successful. Welcome to visit our factory! - We are passionate about driving results. Welcome to visit our factory! - From Fortune 500 to Family-Owned, We Help Manage Supply Chains of All Sizes. Welcome to visit our factory!
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
WELLCAMP has more than 19 years of experience in export and production prefab House. For 19 years, our container houses, steel structures, prefab House, portable toilets have been sold to more than 60 countries.
