Tailored Camp Solutions to Meet  Custom Needs.

project prefab houses china on seaside for accommodation worker 1
project prefab houses china on seaside for accommodation worker 2
project prefab houses china on seaside for accommodation worker 3
project prefab houses china on seaside for accommodation worker 4
project prefab houses china on seaside for accommodation worker 5
project prefab houses china on seaside for accommodation worker 6
project prefab houses china on seaside for accommodation worker 7
project prefab houses china on seaside for accommodation worker 8
project prefab houses china on seaside for accommodation worker 9
project prefab houses china on seaside for accommodation worker 10
project prefab houses china on seaside for accommodation worker 1
project prefab houses china on seaside for accommodation worker 2
project prefab houses china on seaside for accommodation worker 3
project prefab houses china on seaside for accommodation worker 4
project prefab houses china on seaside for accommodation worker 5
project prefab houses china on seaside for accommodation worker 6
project prefab houses china on seaside for accommodation worker 7
project prefab houses china on seaside for accommodation worker 8
project prefab houses china on seaside for accommodation worker 9
project prefab houses china on seaside for accommodation worker 10

project prefab houses china on seaside for accommodation worker

Price Term:
FOB C&F CIF
Port:
Nansha/Huangpu Port
Payment Term:
TT/LC
MOQ:
100 Square Meters
Delivery Time:
20-25 days
Brand Name:
WELLCAMP
Inquiry
Company Advantages
1. The quality control of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated houses china is considered to be sophisticated. The control limits are established for a certain process such as temperature.
2. [企业简称] strictly controls the design and production process. We make sure that prefab houses china is scientific in design, stable in performance and high in quality.
3. The main character of the prefab houses china is that it has prefabricated houses china . It is made of environmentally-friendly materials to protect the ecological system
4. prefab houses china represents the wisdom crystallization of our outstanding prefabricated houses china . Its color, size, and shape can be customized to meet customer's requirements
5. prefab houses china has attracted much attention as a prefabricated houses china based on concrete houses in usa character. The service life of the product is more than 20 years
  ◆◆ Product Detail


SortNameSpecification



Size


Length5K(9.26m)
Width5K(9.26m)
Height3P(2.85m)
Total area                       85.75 m²



Steel structure


Column"C" section steel
Beam"C" section steel
Purlin"C" section steel


Panel


Wall panel50mm EPS sandwich panel
Roof panel50mm EPS sandwich panel


Accessories


Window1740*925 aluminum sliding window
 Door Double open stee door

WELLCAMP, WELLCAMP prefab house, WELLCAMP container house- Mobile Low Cost steel Prefab House For Laundefined


WELLCAMP, WELLCAMP prefab house, WELLCAMP container house- Mobile Low Cost steel Prefab House For La-2WELLCAMP, WELLCAMP prefab house, WELLCAMP container house- Mobile Low Cost steel Prefab House For La-3

Mexico Project. These smart houses are used as students' classrooms. 40 children study in one classroom.

This school project has 30 sets of classrooms, two offices, one clinic, one store and one big playground.



  ◆◆ Product  Features


1. The unit figure for K house dimension is K. 1k=1.82m

2.K house can be done as 1 floor, 2 floors or 3 floors building.

      Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ).

3. K house is commonly used with qualified waterproof, fireproof (EPS/Rock        wool/IEPS/PU sandwich panel), heat insulation and sound insulation performance.

4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times.

5.K house is Anti worm and ant. All steel structures are well painted and

      anti-rust which can be normally used for over 15 years with very limited amount of building wastes.

6.K house only requires level concrete floor for the foundation.

7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day.


  ◆◆ Main   Material



K-House 3D model


undefined


Material parameters

 Main steel:C section steel for column & beam;

Wall panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Roof panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Window:Aluminum sliding window;

Door:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door;

Ridge capping: 0.326/0.376/0.426mm single steel sheet.


  ◆◆ Product  Parameter


Wind resistance

Grade 11(wind speed≤120 km/h)

Earthquake resistance

Grade 7

Snow load capacity of roofing

0.6 kn/m²

Live load capacity of roofing

0.6 kn/m²

External and internal wall heat transmission coefficient

0.35 kcal/m²hc

Wall permitted loading

0.6 kn/m²

Second floor load capacity

180kg/m²

Live load of corridor

2.5kn/m²

Density of EPS

12 kg/m²

Delivery time

Normally 20-25 days

Container loading

300-320 m² /HQ


  ◆◆ Product    Installation


Installation Photos


Installation Video




  ◆◆ Real Map   Display


WELLCAMP, WELLCAMP prefab house, WELLCAMP container house- Mobile Low Cost steel Prefab House For La-8

This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.


  ◆◆ Certificates





Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD has become a famous enterprise in China. We have earned a wealth of experience in prefabricated houses china development and production.
2. We have exceptional production managers. Relying on strong organization skills, they are capable of managing large production plans and enable the production to meet relevant industry standards.
3. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD's vision is to became the leader in products and services for prefab houses china industry. Check now!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
