prefabricated houses china price customized k16 prefab houses manufacture
1. The Wellcamp folding house can be made in different colors to suit your specific esthetic needs. WELLCAMP, WELLCAMP prefab house, WELLCAMP container house factory has established itself as a leading manufacturer, trader, and manufacture of prefabricated houses china price in the market.
2. Our production area covers more than 20,000 m². WELLCAMP, WELLCAMP prefab house, WELLCAMP container house is full of vitality, energy and warrior spirit.
3. The robust steel structure keeps the folding house made by Wellcamp resistant to heavy wind up to 120km/h and 7 grade earthquake. The main character of the prefab houses,prefabricated house companies is that it has prefabricated houses by chinese companies.
4. Folding container house is fireproof and waterproof. labor camp,prefabricated concrete houses has the advantage of precast concrete houses in south africa, which is used in concrete houses for sale.
| Sort | Name | Specification |
Size | Length | 11.08m |
| Width | 7.44m | |
| Height | 2.85m | |
| Total area | 87.98m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm rock wool sandwich panel |
| Roof panel | 50mm rock wool sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Rock wool door | |
Middle East prefab labor camp project. Around 1000 sets rooms for the labor wokers.
This 88m2 apartment have the bedroom, toilet and kitchen. Cemment foundation.
◪1.Unit figure for K house dimension is K. 1k=1.82m. |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3.K house is commonly used with qualified water proof, fire proof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4.K house use Reusable materials and is more environment friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7.labors one team, each day can install more than 300 m2. |
K-House 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
