modular k2 prefab houses sale
1. The shaping desigh of prefab houses is fit perfectly fit in your hands.We have a professional team of installment engineers with more than 15 years of experience
2. If You Are Interested In Our High-Quality Products And Related Service, Pls Contact Us, Wellcamp prefab houses can be widely used in temporary construction such as office, accommodation, soldier camp mobile toilet, etc,Customers Are Happy With The Top Quality And Reasonable Price Of 'S prefabricated houses china price, Choose From Our Website. You Will Never Be Disappointed.
3. specially-formulated labor camp allow prefabricated house companies– dramatically extending prefabricated houses by chinese companies. The Wellcamp house is fitted with a 300mm-thich floor to meet the requirement of firm foundation.
4. The offered prefab homes is used for prefabricated concrete houses in various industries. The raw materials that we source for the folding house product was stringently inspected by our professional technicians to ensure that they meet customers' requirements
5. precast concrete houses in south africa design produces a superior finish in either application. Successful projects can be provided to clients.
| Sort | Name | Specification |
Size | Length | 32.92m |
| Width | 12.9m | |
| Height | 5.7m | |
| Total area | 849.34m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Double opening steel Door outside and sandwich door inside | |
| Payment terms | T/T,L/C | |
| MOQ | 200 square meter | |
Qatar project. This prefabricated house is for the worker dormitories.Middle wakway and two sides rooms.
One building have 36 rooms,one room can live 6-8 labors,double bed.
◪1.Unit figure for K house dimension is K. 1k=1.82m. |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3.K house is commonly used with qualified water proof, fire proof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4.K house use Reusable materials and is more environment friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7.labors one team, each day can install more than 300 m2. |
K-House 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
