mobile steel prefabricated house online for labour camp

Price Term:
FOB, EXW, CIF, CFR
Port:
Nansha/Huangpu Port
Payment Term:
TT/LC
MOQ:
300 Square Meters
House Style:
k Prefabricated House
Delivery Time:
20-25 days
Brand Name:
WELLCAMP
Inquiry
Company Advantages
1. The production process of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated house manufacturers is regulated according to international standards. The design of the product is a blend of simplicity and utility
2. One benefit is that there are so many accessories that one can have with this product such as container padlocks and container lockboxes (which add additional security), container lighting, container ramps, moisture traps, etc. The material of the product can be recycled
3. This product has a clean surface. Its sheets have gone through surface preparation with sandblasting and priming to remove rust, dirt, contaminants, etc. The service life of the product is more than 20 years
4. This product comes with structural integrity. A steel frame is welded together, corrugated Corten steel is placed on the outside of the frame providing an exterior that can withstand everything thrown at it; wood flooring is then treated and bolted down inside. The product is easy to move and install

 Product Detail


SortNameSpecification



Size


Length27.46m
Width5.62m
Height5.7m
Total area                                                            358.84m2



Steel structure


Column"C" section steel
Beam"C" section steel
Purlin"C" section steel


Panel


Wall panel50mm rock wool sandwich panel
Roof panel50mm rock wool sandwich panel


Accessories


WindowAluminium alloy sliding window
 DoorDouble open steel door
Payment termsT/T,L/C
MOQ200 square meter


undefined

WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Green Modern Prefab Modular House with Rec-1

WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Green Modern Prefab Modular House with Rec-2

WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Green Modern Prefab Modular House with Rec-3

Malaysia Project. The ground floor of this modular house is used for the canteen and the first floor is used for the dormitory.

The wall and roof is fireproof rock wool sandwich panel.



  ◆◆ Product  Features


1. The unit figure for K house dimension is K. 1k=1.82m

2.K house can be done as 1 floor, 2 floors or 3 floors building.

      Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ).

3. K house is commonly used with qualified waterproof, fireproof (EPS/Rock wool/IEPS/PU sandwich panel), heat insulation and sound insulation performance.

 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times.

 5.K house is Anti worm and ant. All steel structures are well painted and

      anti-rust which can be normally used for over 15 years with very limited amount of building wastes.

 6.K house only requires level concrete floor for the foundation.

 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day.


  ◆◆ Main   Material



K-House 3D model


undefined


Material parameters

 Main steel:C section steel for column & beam;

Wall panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Roof panel:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel;

Window:Aluminum sliding window;

Door:50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door;

Ridge capping: 0.326/0.376/0.426mm single steel sheet.


  ◆◆ Product  Parameter


Wind resistance

Grade 11(wind speed≤120 km/h)

Earthquake resistance

Grade 7

Snow load capacity of roofing

0.6 kn/m²

Live load capacity of roofing

0.6 kn/m²

External and internal wall heat transmission coefficient

0.35 kcal/m²hc

Wall permitted loading

0.6 kn/m²

Second floor load capacity

180kg/m²

Live load of corridor

2.5kn/m²

Density of EPS

12 kg/m²

Delivery time

Normally 20-25 days

Container loading

300-320 m² /HQ


  ◆◆ Product    Installation


Installation Photos


Installation Video




  ◆◆ Real Map   Display


WELLCAMP, WELLCAMP prefab house, WELLCAMP container house-Green Modern Prefab Modular House with Rec-8

This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
