k19 camp prefab houses three
1. Our prefab houses are highly demanded all across the globe for its vast features & specifications.
2. In order to keep pace with ever-changing demands of customers, our company is committed to offering high-quality products. Wellcamp adopts FACTORY TO CUSTOMER commercial model, cutting off the traditional agent and distributor to ensure that we are offering the lowest price
3. Main drive adopts high accurate labor camp, with an output much higher than prefabricated houses china price. The Wellcamp folding house can be made in different colors to suit your specific esthetic needs
4. 's success lies in our ability to integrate seamlessly with your unique commercial requirements, delivering an end-to-end service for you and your customer whilst remaining invisible throughout the entire process. Wellcamp's folding container house has been reported by 7 Days, Asia's famous media, and has received appreciation from foreign government for its amazing convenience in urgent housing
| Sort | Name | Specification |
Size | Length | 32.92m |
| Width | 12.9m | |
| Height | 5.7m | |
| Total area | 849.34m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Double opening steel Door outside and sandwich door inside | |
| Payment terms | T/T,L/C | |
| MOQ | 200 square meter | |
Qatar project. This prefabricated house is for the worker dormitories.Middle wakway and two sides rooms.
One building have 36 rooms,one room can live 6-8 labors,double bed.
◪1.Unit figure for K house dimension is K. 1k=1.82m. |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3.K house is commonly used with qualified water proof, fire proof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4.K house use Reusable materials and is more environment friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7.labors one team, each day can install more than 300 m2. |
K-House 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. The offered prefab houses are manufactured at our vendors’ end by using best grade raw material and cutting edge technology in tune with industry set norms and guidelines.
2. We can be trusted because that’s all we have for our customers–the truth. Please Contact Us!
