house k9 prefab houses
1. A broad range of prefab houses by can suit every requirement and application, from prefabricated houses china price to prefabricated house companies. We have 13 years of experience in the industry
2. The professionals recruited by us are holds detailed knowledge and vast experience in this domain. Our container houses have been recognized worldwide
3. labor camp offered by us is widely used in prefabricated houses by chinese companies. Another advantage of wellcamp house is that it is movable by crane and forklift
| Sort | Name | Specification |
Size | Length | 11.08m |
| Width | 7.44m | |
| Height | 2.85m | |
| Total area | 87.98m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm rock wool sandwich panel |
| Roof panel | 50mm rock wool sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Rock wool door | |
Middle East prefab labor camp project. Around 1000 sets rooms for the labor wokers.
This 88m2 apartment have the bedroom, toilet and kitchen. Cemment foundation.
◪1.Unit figure for K house dimension is K. 1k=1.82m. |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3.K house is commonly used with qualified water proof, fire proof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4.K house use Reusable materials and is more environment friendly compared to traditional buildings. It can be assembled and disassembled six times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7.labors one team, each day can install more than 300 m2. |
K-House 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. Wellcamp Building Materials has gained success in the market by manufacturing a remarkable gamut of prefab houses. - Good Wine Needs No Bush. Offers Ergonomically Designed labor camp, prefabricated houses china price, prefabricated house companies. Inquire!
2. Get More Info! 's prefab homes, prefabricated houses by chinese companies, prefabricated concrete houses Is Made Of High Quality Materials And Through Professional Production Line. Do Feel Free To Contact Us.
3. Sloth Tarnishes The Edge Of Wit. 's tiny houses prefab, precast concrete houses in south africa, concrete houses for sale Enjoy High Reputation In The Global Market. Inquire Online! - , A company you can rely on. Check Now!
