Sort | Name | Specification |
Size | Length | 9m |
Width | 6m | |
Height | 2.6m | |
Total area | 54.2m2 | |
Steel structure | Column | Square tube |
Beam | Square tube | |
Purlin | C section steel | |
Panel | Wall panel | 50mm IEPS sandwich panel |
Roof panel | 50mm IEPS sandwich panel | |
Accessories | Window | Aluminum sliding window |
Door | Steel Door |
Light steel container villa Characteristics
1. The house is movable and portable by crane and forklift.
2. It has a good fire proof, noise proof and heat insulation performance because of the IEPS sandwich panel we use for wall and roof.
3. Compared with the civil building, easy construction, low cost, time-saving, labor saving and convenient transportation.
4. The steel structures make the house resisting heavy wind of 120 km/h and 7 grade earthquakes.
5. Anti worm and ant. All the steel structure is painted and anti-rust which can be normally used for more than 15 years without any building garbage.
6. Outside the house, you can stick the PVC or PU decoration sheet.
7. Environment materials, it can be assembled and disassembled six times.
IEPS wall and roof panel
20mm plywood plate
Beam
Ring beam
Light steel container villa Accessories Materials
We firmly believe success depends on details. In order to ensure our excellent quality, beside professional talent, advanced technology, we also has 3 person responsibilities for quality Inspection. Our production line has 3 times quality check. Fist time is before production check, which for the raw materials’ thickness and quality. Second time is middle production check, which for the welding, descaling and the size. Third time is after production check, which for the painting and the package.
We believe that the perfect quality is our pride, what push us move forward greatly is more and more customers’ reorganization and flowing. Establish and protect our own brand is we always seek.
Light steel container Technical parameter
Wind resistance | Grade 11(wind speed≤120 km/h) |
---|---|
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Density of cement board | 37kg/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 6 Sets/HQ |
Light steel container villa Installation Photos
