WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefab houses for sale wholesale for labour camp
1. Different factors have been taken into consideration during the design of WELLCAMP, WELLCAMP prefab house, WELLCAMP container house prefabricated houses china . They are space planning, room layout, furniture layout, as well as the whole space integration. All its steel bars have anti-rust treatment, which can provide long-term durability
2. The most important benefit of decorating a space with this product is that it will make the space appeal to the users' particular style and senses. Its materials prove to have premium plasticity and toughness
3. The product is highly appreciated for its high performance and long service life. It provides users with a safe and comfortable living environment
| Sort | Name | Specification |
Size | Length | 27.46m |
| Width | 5.62m | |
| Height | 5.7m | |
| Total area | 358.84m2 | |
Steel structure | Column | "C" section steel |
| Beam | "C" section steel | |
| Purlin | "C" section steel | |
Panel | Wall panel | 50mm rock wool sandwich panel |
| Roof panel | 50mm rock wool sandwich panel | |
Accessories | Window | Aluminium alloy sliding window |
| Door | Double open steel door | |
| Payment terms | T/T,L/C | |
| MOQ | 200 square meter | |
Malaysia Project. The ground floor of this modular house is used for the canteen and the first floor is used for the dormitory.
The wall and roof is fireproof rock wool sandwich panel.
◪1. The unit figure for K house dimension is K. 1k=1.82m |
◪2.K house can be done as 1 floor, 2 floors or 3 floors building. Figures for house with different stories: One floor=3P, two floor=6p, three floor=9p ( 1P=0.95m ). |
◪3. K house is commonly used with qualified waterproof, fireproof （EPS/Rock wool/IEPS/PU sandwich panel）, heat insulation and sound insulation performance. |
◪ 4. K house uses reusable materials and is more environment-friendly compared to traditional buildings. It can be assembled and disassembled 6 times. |
◪ 5.K house is Anti worm and ant. All steel structures are well painted and anti-rust which can be normally used for over 15 years with very limited amount of building wastes. |
◪ 6.K house only requires level concrete floor for the foundation. |
◪ 7. 6 labors constitute one team, which can install areas of more than 300 ㎡ each day. |
K-House 3D model
Material parameters
Main steel：C section steel for column & beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
Ridge capping: 0.326/0.376/0.426mm single steel sheet.
Wind resistance | Grade 11(wind speed≤120 km/h) |
Earthquake resistance | Grade 7 |
Snow load capacity of roofing | 0.6 kn/m² |
Live load capacity of roofing | 0.6 kn/m² |
External and internal wall heat transmission coefficient | 0.35 kcal/m²hc |
Wall permitted loading | 0.6 kn/m² |
Second floor load capacity | 180kg/m² |
Live load of corridor | 2.5kn/m² |
Density of EPS | 12 kg/m² |
Delivery time | Normally 20-25 days |
Container loading | 300-320 m² /HQ |
This prefab house can be used as the dormitory, office, school, canteen, store room, shop, clinic and so on. The materials of the house are very environment-friendly. It can be assembled and disassembled 6 times. For more information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is in a leading position in the world in the field of study and production technique of prefab houses for sale .
2. We have imported state-of-the-art manufacturing facilities years ago. With a significant advantage in high-efficient facilities, these facilities guaranteed the shortest delivery time.
3. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is committed to the creation of well-being to the general public in a sustainable way. Welcome to visit our factory!
