Modern Living Detachable Container House, Wellcamp C-6
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD can satisfy different design requirements. Its outer appearance is characterized by vivid color
2. People can believe the fact that by using this product, the return to their pockets through savings on electricity bills will only increase. The service life of the product is more than 20 years
3. The product is of high quality. Not only its raw materials are ultra-high purity without no unnecessary impurities, but also its workmanship is done by advanced techniques. All its steel bars have anti-rust treatment, which can provide long-term durability
4. The product is scratch and wear resistance. Its materials are all abrasion-proof and have excellent chemical and physical strength and stiffness. Its stable quality is achieved by the efforts of the design team, engineer team, innovation team, and QC team
| Sort | Name | Specification |
Size | Length | 9.504m |
| Width | 6.058m | |
| Height | 5.7m | |
| Total area | 142.16m² | |
Steel structure | Column | Square tube |
| Beam | Square tube | |
| Purlin | “C” section steel | |
Panel | Wall panel | 50mm EPS sandwich panel |
| Roof panel | 50mm EPS sandwich panel | |
Accessories | Window | 1200*930 aluminum sliding window |
| Door | Steel Door | |
◪1.Modern & High end design, Detachable Ripple Container house is the Newest prefab house trend in 2017. |
◪2.Corrugated appearance outside for Oceanic Style & Wood grain painting inside for indoor comfort, Better Looking than normal. |
◪3.IEPS panel for wall & roof, 100% fire proof and water proof, the One & Only. |
◪ 4.Galvanized main frame, Stronger, more Durable & Extra Anti-corrosion. |
◪ 5.Size:3mX6MX2.85H and customizable, Better choice for DIY. |
◪ 6.1*40HQ shipping container can load 12 sets, More Cost-Saving. |
◪ 7.Can be stacked up to 3 floors & can be set up manually, Easier to Build. |
Detachable container house 3D model
Material parameters
Main steel：C section steel for column&beam；
Wall panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Roof panel：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel；
Window：Aluminum sliding window；
Door：50/75/100mm EPS/IEPS/Rock wool/PU Sandwich panel or steel door；
ridge capping： 0.326/0.376/0.426mm single steel sheet.
Size: | 3MX6MX2.85H |
Wind resistance: | Grade 11 |
Earthquake resistance: | Grade 8 |
External and internal wall heat transmission coefficient: | 0.35 kcal/m2hc |
Wall permitted loading: | 0.6 kn/m2 |
Wall and roof panel: | 50mm IEPS panel |
Weight of the container: | 1.2T (IEPS panel) |
Window: | Double glass aluminum window |
Door: | Steel door |
Delivery time: | Normally 20-25 days |
Loading: | 12 Sets/HQ |
This detachable container house can be used as the dormitory,office,school,canteen,store room,shop,clinic and so on, The materials of the house is very environment friendly. It can be assemed and disassemed for six times. More information about it, welcome to contact us.
Company Features
1. Guangdong WELLCAMP BUILDING MATERIALS CO., LTD is a high-tech listed company, which primarily engages in container house .
2. Our technology ability is recognized not only by our global customers but also by authoritative institutions.
3. We aim at the good quality flat pack living container house industry, and would like to be number one in this field.
